Paneltronics Breaker 25 Amps A-Frame Magnetic Waterproof

Click to enlarge

Paneltronics Breaker 25 Amps A-Frame Magnetic Waterproof

Original price was: $34.95.Current price is: $21.51.

Manufacturer: Paneltronics | Manufacturer Part Number: 206-055S | UPC Code: 602290201442

Out of stock

Fast Shipping

Timely delivery with all orders

30 Day Return

Return accepted on selected items

24/7 Help

Help is just around the corner.

Add to wishlist

SKU: 29832 Categories: Electrical, Switches & Accessories

Description

SKU: 29832

Manufacturer: Paneltronics

Manufacturer Part Number: 206-055S

UPC Code: 602290201442

Panel Seal / Waterproof “A” Frame Magnetic Circuit Breakers

Branch AC or DC circuit breaker for Paneltronics electrical distribution panels

Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers

UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada

Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)

Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
Specifications

Handle Color: Metal with Silicon rubber seal
Maximum Amperage: 50 Amps
Maximum Voltage/AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage
Electrical Hardware: Screw 10-32 x 3/8″ pan combo head (P/N 197-188)
Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker), Lockwasher 1/2″ internal tooth (supplied with circuit breaker)
Optional Boot Black silicone rubber (P/N 048-015)

Additional information

Weight	0.2 lbs
